Description
Pulling force max. 10 – 23 t
The harder the pulling force, the tighter the grip of the jaws. Longer jaws up to 1000 mm are available on request.
Features
• High quality components from our standard hydraulic programme.
• Modular system, hydraulic parts can also be used for many other applications.
• Long-life hydraulic cylinders manufactured from chromium-molybdenum steel.
• Two-stage quick-action hand pumps.
• Incl. high pressure hydraulic hose with quick coupler, L = 2.0 m.
• All complete sets are supplied in metal box model HPK-10 or wooden case.
• All sets are supplied ready to use.
Scope of delivery:
• Pressure gauge set model GYA-63.
