Description
The SS.QLR (Quick Lift Ring) or SS.QL.DSR is a double swivel ring in stainless steel that allows particularly fast mounting. At the push of a button, it can be fixed in the threaded hole with a simple click. Its double swivel ensures a perfect alignment with the sling. The QL.DSR saves up to 80 % of time compared to screwing in a conventional lifting ring. The system works purely mechanically and thus requires no complex maintenance.
Just like all of CODIPRO’s stainless-steel lifting rings, the SS.QL.DSR provides perfect corrosion resistance. This ensures optimal longevity of the lifting ring and allows it to be used in humid, chemical, marine environments, etc.
It can be used for any lifting configuration (straigt lift, with angle, tilting, rotating) by applying the tightening torque engraved on the ring.
The SS.QL.DSR lifting ring is designed for use in a temperature range from -20°c to +200°c and carries various markings, including CE, WLL and tightening torque. It is manufactured in compliance with the REACH regulation and is also available in stainless-steel.
No circlips
No ball bearing
- Safety factor 4:1 et 5:1
- Stainless steel 316L
- swiveling under load
- Rotation 360° – Swivel 180°
- Complies with the Machinery Directive 2006/42/CE
- Manufactured in compliance with the EN 1677-1
- Individual traceability number
